Yale NR040DA Specs
Quick-reference specifications for the Yale NR040DA forklift, taken from the manufacturer’s spec sheet.
- Rated Capacity
- 4000 lb1814 kg
Performance 14 specs
| Rated Capacity | 4000 lb (1814 kg) |
|---|---|
| Carriage Tilt Angle (forward / back) | 3° Fwd / 4° Back |
| Stability – Comply with ANSI | Yes |
| Travel Speed Rearward (chassis first) – Empty / Rated Load | 6.5/6.05 mph |
| Lift Speed Empty | 60 ft/min |
| Lift Speed 2000 | 46 ft/min |
| Lift Speed 3000 | 43 ft/min |
| Lift Speed 3500 | 40 ft/min |
| Lift Speed 4000 | 38 ft/min |
| Lowering Speeds – Standard / Optional Empty | 85 ft/min |
| Lowering Speeds – Standard / Optional Rated Load | 85 ft/min |
| Size – front load wheels (tandem articulating) Standard | 5 x 3.9 |
| Brakes, service / parking – Method of Control | Foot |
| Brakes, service / parking – Method of Operation | Spring Apply / Electric Release |
Dimensions 5 specs
| Load Center | 24 in (610 mm) |
|---|---|
| Tire type Load / Caster / Drive | Poly / Poly / Rubber |
| Forks Standard (length x width x thickness) | 1.80 x 3.9 x 42 in |
| Size – drive tire / dual casters Standard – Drive | 12.0 x 5.5 |
| Size – drive tire / dual casters Standard – Caster | 7.9 x 2.2 |
Power / Engine 8 specs
| Power type | Electric – 24 volt |
|---|---|
| Truck Weight without Battery (approximate) | 5000 lb |
| Battery Compartment Size – 12.5″ Battery Compartment | 39.0 x 12.5 x 31.5 in |
| Battery Compartment Size – 14.5″ Battery Compartment | 39.0 x 14.5 x 31.5 in |
| Battery Compartment Size – 16.5″ Battery Compartment | 39.0 x 16.5 x 31.5 in |
| Battery, type | Lead Acid |
| Traction motor control method | Transistor |
| Hoist motor control method | Transistor |
