Forklift · Caterpillar
Caterpillar GP18 Specs
Quick-reference specifications for the Caterpillar GP18 forklift, from the manufacturer’s spec sheet and published specifications.
Performance 8 specs
| Rated speed to DIN | 70 020 |
|---|---|
| Load Capacity | 3,500 lb (1,750 kg) |
| Travel Speed – Loaded | 19 km/h |
| Travel Speed – Unloaded | 19.5 km/h |
| Hoisting Speed – Loaded | 0.64 m/s |
| Hoisting Speed – Unloaded | 0.65 m/s |
| Lowering Speed – Loaded | 0.52 m/s |
| Turning Radius | 6.5 ft (1.98 m) |
Dimensions 4 specs
| Fork carriage to DIN | 15 173 A/B/no |
|---|---|
| Overall Length | 11.5 ft (3,500 mm) |
| Overall Width | 42 in (1,065 mm) |
| Lifting Height | 9.8-10.8 ft (3.0-3.3 m) |
Weight 1 spec
| Nominal Weight | 6,105 lb (2,770 kg) |
|---|
Power / Engine 3 specs
| Engine Type | Mitsubishi 4 G 63 |
|---|---|
| Engine Power | 42 HP (31 kW) |
| Number of Cylinders | 4 |
