- Caterpillar GP15N
Forklift · Caterpillar
Caterpillar GP15N Specs
Quick-reference specifications for the Caterpillar GP15N forklift, from the manufacturer’s spec sheet and published specifications.
- Gradeability – Full Load
- 63%
Performance 11 specs
| Rated speed to DIN | 70 020 |
|---|---|
| Load Capacity | 3,000 lb (1,361 kg) |
| Travel Speed – Full Load (Forward/Reverse) | 10.9 mph (17.5 km/h) |
| Travel Speed – Empty | 11.8 mph (19 km/h) |
| Lifting Speed – Full Load | 122 fpm (0.62 m/s) |
| Lifting Speed – Empty | 124 fpm (0.63 m/s) |
| Lowering Speed – Full Load | 98.4 fpm (0.52 m/s) |
| Gradeability – Full Load | 63% |
| Maximum Drawbar Pull | 4,560 lb |
| Turning Radius (Outside) | 76.8 in (1.95 m) |
| Load Center Distance | 24 in (500 mm) |
Dimensions 12 specs
| Fork carriage to DIN | 15 173 A/B/no |
|---|---|
| Length to Fork Face | 89 in (2.26 m) |
| Overall Width (Single Tires) | 41.9 in (1.06 m) |
| Mast Lowered Height | 84.5 in (2.14 m) |
| Overhead Guard Height | 82.7 in (2.10 m) |
| Wheelbase | 55.1 in (1.40 m) |
| Seat Height | 44.4 in to 46.7 in (1.13 m to 1.19 m) |
| Fork Spread (Outside) | 7.9 in to 36.2 in (20 cm to 92 cm) |
| ForkSize(T×W×L) | 1.4 × 3.9 × 42 in |
| Tilt Range Forward/Backward | 6°/10° |
| Underclearance – Minimum (Mast) | 4.3 in (109 mm) |
| Ground Clearance – Center of Wheelbase | 6 in (152 mm) |
Weight 1 spec
| Total Weight (Without Load) | 5,650 lb (2,563 kg) |
|---|
Power / Engine 7 specs
| Engine Make/Model | GK21E |
|---|---|
| Engine Cylinders | 4 |
| Displacement | 126 cu in (2.065 L) |
| Rated Horsepower @ RPM | 53 hp @ 2,700 rpm (41 kW) |
| Rated Torque @ RPM | 110 lb-ft @ 1,800 rpm (149 Nm) |
| Battery Voltage | 12 V |
| Sound Level (ANSI B56.11.5) | 73.5 dB |
Hydraulics / Fluids 4 specs
| Fuel Tank Capacity | 2.1 L |
|---|---|
| Auxiliary Hydraulic Function – Max Operating Pressure | 2,610 psi |
| Free-Lift (Top of Forks) | 4.5 in (114 mm) |
| Load Distance (Center of Wheel to Face of Forks) | 15.7 in (399 mm) |
