Forklift · Doosan
Doosan BW23S-7 Specs
Quick-reference specifications for the Doosan BW23S-7 forklift, taken from the manufacturer’s spec sheet.
- Capacity @ 24″ LC
- 4500 lb2045 kg
Performance 4 specs
| Capacity @ 24″ LC | 4500 lb (2045 kg) |
|---|---|
| Load Center | 24.0 in (600 mm) |
| Service Brake | Electro-Magnetic |
| Outside Turning Radius | 64.9 in (1650 mm) |
Dimensions 10 specs
| Drive Tire | 10.0 x 3.0 in (250 x 70 mm) |
|---|---|
| Max. Fork Height | 7.9 in (202 mm) |
| Fork Lowered Height | 3.2 in (82 mm) |
| Length to Forkface | 21.8 in (555 mm) |
| Wheelbase | 52.4 in (1331 mm) |
| Overall Length | 69.9 in (1775 mm) |
| Recommended Aisle Width | 84.1 in (2135 mm) |
| Overall Width | 30.5 in (775 mm) |
| Ground Clearance | 1.1 in (28 mm) |
| Fork Dimensions | 27.0 x 48.0 in (686 x 1220 mm) |
Power / Engine 4 specs
| Power Type | 24 V Electric AC |
|---|---|
| Battery Conn/Lead/Position | SB175 Red/B |
| Battery Compartment Length | 7.9 in (200 mm) |
| Battery Weight | 375 lb (170 kg) |
