Telehandler · Genie

Genie AGRI-730 Specs

Quick-reference specifications for the Genie AGRI-730 telehandler, compiled from published specifications.

Lift capacity at maximum height: 5,511 lb2,500 kg

Performance 6 specs

Lifting height maximum	22 ft 8 in (6.90 m)
Forward reach maximum	13 ft 1 in (3.99 m)
Reach at maximum height	2 ft 6 in (76 cm)
Lifting capacity maximum	6,613 lb (3,000 kg)
Lift capacity at maximum height	5,511 lb (2,500 kg)
Lift capacity at maximum reach	2,755.5 lb (1,250 kg)

Dimensions 10 specs

Height	6 ft 9 in (2.07 m)
Height at steering wheel	4 ft 5 in (1.35 m)
Width	6 ft 6 in (1.99 m)
Inside cab width	2 ft 5 in (75 cm)
Track	5 ft 3 in (1.59 m)
Wheelbase	8 ft 8 in (2.66 m)
Overall length	19 ft 5 in (5.91 m)
Ground clearance	500 mm
Internal steering radius	2200 mm
External steering radius	3800 mm

Weight 1 spec

Weight with forks	12,987 lb (5,900 kg)

Power / Engine 4 specs

Engine type	Deutz TD2011 L04W Tier 3 diesel
Engine power	68 kW (68 hp) at 2600 rev/min
Max torque	210 Nm (155 lb-ft) at 1700 rev/min
Tire pressure	80 psi (5.5 bar)
