Forklift · Hyster
Hyster N30ZDR2 Specs
Quick-reference specifications for the Hyster N30ZDR2 forklift, from the manufacturer’s spec sheet and published specifications.
- Rated Capacity
- 3,000 lb1,361 kg
Performance 9 specs
| Rated Capacity | 3,000 lb (1,361 kg) |
|---|---|
| Load Center Distance | 24 in (610 mm) |
| Travel Speed – Rearward (empty/loaded) | 7.4 mph / 6.5 mph |
| Travel Speed – Forward (empty/loaded) | 7.4 mph / 6.5 mph |
| Lift Speed – Empty | 100 ft/min |
| Lift Speed – 2,000 lb Load | 98 ft/min |
| Turning Radius (14.5″ battery compartment) | 65.74 in |
| Turning Radius (16.5″ battery compartment) | 67.74 in |
| Turning Radius (18.5″ battery compartment) | 69.90 in |
Dimensions 12 specs
| Width Across Mast Channels (5.5″ Standard Mast) | 30.0 in (762 mm) |
|---|---|
| Width Across Mast Channels (5.5″ HD Mast) | 30.2 in (767 mm) |
| Width Across Mast Channels (6.9″ Mast) | 31.6 in (802 mm) |
| Wheelbase (14.5″ battery compartment) | 55.35 in |
| Wheelbase (16.5″ battery compartment) | 57.36 in |
| Overall Width | 40.2 in |
| Overhead Guard Height | 86.3 in |
| Battery Compartment Size (14.5″) | 39.0 x 14.5 x 31.5 in |
| Battery Compartment Size (16.5″) | 39.0 x 16.5 x 31.5 in |
| Battery Compartment Size (21.5″) | 39.0 x 21.5 x 31.5 in |
| Forks – Standard (1.6″ Hook Type) | 1.6 x 3.9 x 42 in (40 x 100 x 1,067 mm) |
| Forks – Standard (1.8″ Hook Type) | 1.8 x 3.9 x 42 in (45 x 100 x 1,067 mm) |
Weight 3 specs
| Empty Weight | 7,800 lb (3,541 kg) |
|---|---|
| Weight (European spec, with Triplex mast) | 5,247 lb (2.38 t) |
| Battery Weight (European spec) | 2,358 lb (1.07 t) |
Power / Engine 3 specs
| Battery Voltage | 36 volt |
|---|---|
| Traction Motor Rating (60-minute) | 7.5 hp (5.6 kW) |
| Hoist Motor Rating (5-minute) | 14.8 hp (11.0 kW) |
Hydraulics / Fluids 2 specs
| Load Wheels | 4 |
|---|---|
| Drive Tire Size | 12.0 x 5.5 in |
