JLG 5394RT Specs
Quick-reference specifications for the JLG 5394RT scissor lift, compiled from published specifications.
- Platform Capacity
- 1,500 lb680 kg
- Capacity on Platform Extension
- 500 lb227 kg
- Platform Height (Lowered)
- 7 ft2.13 m
- Gradeability
- 40%
Performance 13 specs
| Max Platform Height | 53 ft (16.2 m) |
|---|---|
| Platform Capacity | 1,500 lb (680 kg) |
| Capacity on Platform Extension | 500 lb (227 kg) |
| Number of Occupants | 6 |
| Lift Time | 65 seconds |
| Lower Time | 60 seconds |
| Maximum Drive Height | 32 ft (9.75 m) |
| Drive Speed (Platform Lowered) | 3.5 mph (5.6 km/h) |
| Drive Speed (Platform Elevated) | 0.5 mph (0.80 km/h) |
| Gradeability | 40% |
| Ground Bearing Pressure | 90 psi (6.3 kg/cm²) |
| Max Tilt Rating – Side-to-Side | 1.5 degrees |
| Max Tilt Rating – Fore and Aft | 1.5 degrees |
Dimensions 14 specs
| Machine Length | 17 ft (5.18 m) |
|---|---|
| Machine Width | 7 ft 7 in (2.31 m) |
| Machine Height (Stowed) | 10 ft 1 in (3.07 m) |
| Machine Height (Rails Folded) | 7 ft 9 in (2.36 m) |
| Wheelbase | 9 ft 9 in (2.97 m) |
| Ground Clearance | 12 in (0.3 m) |
| Turning Radius (Inside) | 9 ft (2.74 m) |
| Turning Radius (Outside) | 19 ft 9 in (6.02 m) |
| Platform Dimension A | 5 ft 11 in (1.79 m) |
| Platform Dimension B | 12 ft 6 in (3.8 m) |
| Platform Extension Length | 4 ft (1.22 m) |
| Platform Height (Lowered) | 7 ft (2.13 m) |
| Platform Railing Height | 3 ft 8 in (1.1 m) |
| Platform Size (Width x Length) | 70.5 x 149.8 in (1.8 x 3.8 m) |
Weight 1 spec
| Machine Weight (with one extension) | 17,110 lb (7,761 kg) |
|---|
Power / Engine 6 specs
| Engine Type – Diesel | D1305 |
|---|---|
| Engine Power – Diesel | 24.8 hp (18.5 kW) |
| Engine Type – Dual Fuel | WG972 |
| Engine Power – Dual Fuel | 31 hp (23 kW) |
| Fuel Tank Capacity | 22 gal (83.28 L) |
| Drive | 4-wheel drive |
Hydraulics / Fluids 1 spec
| Hydraulic Reservoir Capacity | 32 gal (121.4 L) |
|---|
