JLG 80SL Specs
Quick-reference specifications for the JLG 80SL boom lift, taken from the manufacturer’s spec sheet.
- Platform Capacity
- 1,653 lb750 kg
- Platform Height–Elevated
- 80 ft 4 in24.50 m
Performance 5 specs
| Platform Capacity | 1,653 lb (750 kg) |
|---|---|
| Lift/Lower Time | 90/70 sec |
| Drive Speed–Elevated | 0.3 mph (0.5 kmph) |
| Drive Speed–Lowered 2WD | 1.7 mph (2.8 kmph) |
| Drive Speed–Slow 4WD | 1.0 mph (1.5 kmph) |
Dimensions 6 specs
| Platform Height–Elevated | 80 ft 4 in (24.50 m) |
|---|---|
| Platform Railing Height | 3 ft 7 in (1.10 m) |
| Stowed Height–Rails Folded | 10 ft 8 in (3.25 m) |
| Platform Size | 98.4 x 210.6 in (2.50 x 5.35 m) |
| Platform Length-Fully Extended | 24 ft 9 in (7.55 m) |
| Ground Clearance | 12 in (30 cm) |
