Vertical Mast · JLG
JLG Ecolift 50 Specs
Quick-reference specifications for the JLG Ecolift 50 vertical mast, taken from the manufacturer’s spec sheet.
- Rated Capacity
- 330 lb150 kg
- Platform Height
- 5 ft1.50 m
- Working Height
- 11 ft3.50 m
- Weight
- 432 lb196 kg
Performance 4 specs
| Working Height | 11 ft (3.50 m) |
|---|---|
| Rated Capacity | 330 lb (150 kg) |
| Maximum Gradient | 5 degrees |
| Wind Speed | 0 mph |
Dimensions 9 specs
| Platform Height | 5 ft (1.50 m) |
|---|---|
| Stowed Height | 61 in (1.55 m) |
| Machine Width | 28 in (0.7 m) |
| Machine Length | 39 in (0.98 m) |
| Platform Size | 28 x 24 in (0.7 x 0.6 m) |
| Platform Length | 28 in (0.7 m) |
| Rail Height | 56 in |
| Machine Height (Stowed) | 61 in (1.55 m) |
| Platform Width | 24 in (0.6 m) |
Weight 2 specs
| Weight | 432 lb (196 kg) |
|---|---|
| Max Ground Bearing Pressure – Rear | 168 psi (11.8 kg/cm2) |
