Telehandler · Manitou
Manitou MHT780 Specs
Quick-reference specifications for the Manitou MHT780 telehandler, taken from the manufacturer’s spec sheet.
- Gradeability (unladen/laden)
- 118% / 50%
Performance 16 specs
| Max. capacity at 600 mm LC | 8000 kg |
|---|---|
| Unladen time – Lifting | 12 s |
| Unladen time – Lowering | 9.0 s |
| Tyres | 18-22.5 16 PR |
| Parking brake | automatic negative handbrake |
| Laden drawbar pull | 10500 daN |
| Gradeability (unladen/laden) | 118% / 50% |
| Max. travel speed | 28 kph |
| Axle | DANA |
| Steering mode | 4 wheel steer 3 steering modes |
| Turning radius (over tyres) | 4.30 m |
| Carriage rotation (crowd/dump) | 12°/124° |
| Noise at driving position (LpA) | 80.8 dB |
| Environmental noise (LwA) | 105 dB |
| Vibration to whole hand/arm | <2.5 m/s² |
| Vibration on driver’s body | <0.5 m/s² |
Dimensions 10 specs
| Max. lifting height | 6.80 m |
|---|---|
| Front wheel centre to carriage | 1.07 m |
| Ground clearance | 0.38 m |
| Overall length to front tyres | 5.22 m |
| Wheelbase | 2.67 m |
| Overall width of cab | 0.86 m |
| Inside tyre width | 1.99 m |
| Overall width | 2.44 m |
| Overall height | 2.52 m |
| Standard forks (length x width x thickness) | 1200 x 200 x 60 mm |
Weight 1 spec
| Unladen weight (with forks) | 12800 kg |
|---|
Power / Engine 4 specs
| Engine | PERKINS |
|---|---|
| Power | 144 HP (106 kW) |
| Max. torque | 556 Nm – 1400 rpm |
| Capacities – Fuel | 120 l |
Hydraulics / Fluids 2 specs
| Load Sensing Pump | 140 l/min – 275 bar |
|---|---|
| Capacities – Hydraulic oil | 140 l |
