Niftylift HR17 Specs
Quick-reference specifications for the Niftylift HR17 aerial lift, taken from the manufacturer’s spec sheet.
- Platform Capacity
- 500 lb225 kg
- Platform Height
- 49 ft 6 in15.00 m
- Working Height
- 56 ft17.00 m
Performance 7 specs
| Working Height | 56 ft (17.00 m) |
|---|---|
| Working Outreach | 31 ft (9.30 m) |
| Fly-Boom Arc | 150° |
| Turning Radius – Outside | 12 ft 2 in (3.70 m) |
| Platform Rotation | 100° |
| Platform Capacity | 500 lb (225 kg) |
| Drive Speed – 4x | 3.4 mph (5.5kmph) |
Dimensions 6 specs
| Platform Height | 49 ft 6 in (15.00 m) |
|---|---|
| Width | 6 ft 7 in (2.00 m) |
| Height | 7 ft (2.15 m) |
| Length – Stowed | 16 ft 5 in (5.00 m) |
| Length – Overall | 20 ft 8 in (6.30 m) |
| Platform Size | 5 ft 11 in x 2 ft 9 in (1.80 m x 0.85 m) |
Weight 1 spec
| Minimum Weight | 10,500 lb (4,750 kg) |
|---|
