Forklift · Raymond
Raymond 8210 Specs
Quick-reference specifications for the Raymond 8210 forklift, from the manufacturer’s spec sheet and published specifications.
- Gradeability (Unloaded)
- 20%
Performance 6 specs
| Load Capacity | 4,500 lb (2,041 kg) |
|---|---|
| Travel Speed (Full Load) | 3.9 mph |
| Gradeability (Unloaded) | 20% |
| Lift Height | 5.5 in (141 mm) |
| Fork Down Height (Min./Max.) | 3.1 / 3.4 in (79 / 86 mm) |
| Fork Raised Height (Min./Max.) | 8.5 / 9.1 in (216 / 231 mm) |
Dimensions 13 specs
| Overall Width | 28 in (711 mm) |
|---|---|
| Overall Length | 44.8 – 72.8 in (1,138 – 1,849 mm) |
| Power Unit Height (Lowered) | 32.7 in (831 mm) |
| Handle Height (Fully Raised) | 47.2 in (1,200 mm) |
| Handle Height (Upper Brake Position) | 46.5 in (1,180 mm) |
| Handle Height (Lower Brake Position) | 26.8 in (680 mm) |
| Handle Height (Fully Lowered) | 23.6 in (600 mm) |
| Bumper to Drive Tire Center | 7.7 in (195 mm) |
| Bumper Underclearance | 2.9 in (75 mm) |
| Fork Width (each) | 6.75 in (172 mm) |
| Actual Fork Overall Width | 26.6 in (675 mm) |
| Head Length | 23.9 in (606 mm) |
| Drive Tire (Rubber) | 10 x 5 in (254 x 127 mm) |
Power / Engine 3 specs
| Battery | 24 V |
|---|---|
| Fork Sizes | 42 in 27 in,48 in 27 in |
| Battery Voltage | 24 Volt |
