Sinoboom GTJZ1212 Specs
Quick-reference specifications for the Sinoboom GTJZ1212 aerial lift, compiled from published specifications.
- Extended Platform Capacity
- 265 lb120 kg
- Max Working Height
- 45 ft 7 in13.9 m
- Gradeability
- 25%
Performance 16 specs
| Max Working Height | 45 ft 7 in (13.9 m) |
|---|---|
| Max Platform Height | 39 ft (11.9 m) |
| Drive Speed – Stowed | 0-2 mph (0-3.2 km/h) |
| Drive Speed – Raised | 0-0.5 mph (0-0.8 km/h) |
| Elevation Time (Unloaded) | 63-68 s |
| Descent Time (Unloaded) | 44-49 s |
| Max Load Capacity | 705 lb (320 kg) |
| Extended Platform Capacity | 265 lb (120 kg) |
| Gradeability | 25% |
| Platform Occupants (Indoor) | 2 |
| Platform Occupants (Outdoor) | 1 |
| Turning Radius (Inside) | 0 ft (0 m) |
| Turning Radius (Outside) | 7 ft 8.5 in (2.35 m) |
| Max Allowable Wind Speed | 12.5 m/s |
| Max Allowable Slope (Front/Back) | 3° |
| Max Allowable Slope (Side/Side) | 1.5° |
Dimensions 8 specs
| Overall Length (Stowed) | 7 ft 10 in (2.39 m) |
|---|---|
| Overall Width (Stowed) | 3 ft 9 in (1.15 m) |
| Overall Height (Stowed, Guardrail Folded) | 6 ft 6 in (1.98 m) |
| Overall Height (Stowed, Guardrail Unfolded) | 8 ft 6 in (2.60 m) |
| Wheelbase | 6 ft 1 in (1.85 m) |
| Ground Clearance | 4 in (0.1 m) |
| Platform Dimensions (L×W×H) | 7 ft 5 in × 3 ft 9 in × 3 ft 7 in (2.25 m × 1.15 m × 1.1 m) |
| Tire Size | 15 × 5 in (380 × 125 mm) solid |
Weight 2 specs
| Weight (Indoor/Outdoor) | 6,394.5 lb (2,900 kg) |
|---|---|
| Weight (Indoor Only) | 5,766 lb (2,615 kg) |
Power / Engine 4 specs
| Power Source | 24 V DC |
|---|---|
| Battery | 12 V × 4 / 300 Ah |
| Drive Mode | 2WD, front-wheel |
| Charger Input | 100-240 V AC |
Hydraulics / Fluids 2 specs
| Hydraulic System Capacity | 7.7 gal (35 L) |
|---|---|
| Control Voltage | 24 V DC |
