Scissor Lift · Skyjack
Skyjack SJII 3220 Specs
Quick-reference specifications for the Skyjack SJII 3220 scissor lift, compiled from published specifications.
- Platform Capacity
- 900 lb408 kg
- Work Height
- 26 ft7.9 m
- Operating Weight
- 3,510 lb1,592 kg
- Gradeability
- 25%
Performance 9 specs
| Work Height | 26 ft (7.9 m) |
|---|---|
| Raised Platform Height | 20 ft (6.1 m) |
| Drive Speed (Stowed) | 2 mph (3.2 km/h) |
| Drive Speed (Raised) | 0.7 mph (1.1 km/h) |
| Gradeability | 25% |
| Turning Radius (Inside) | 50 in (1.3 m) |
| Turning Radius (Outside) | 108 in (2.7 m) |
| Lift Time (With Rated Load) | 33 sec |
| Platform Capacity | 900 lb (408 kg) |
Dimensions 11 specs
| Overall Length | 91.5 in (2.3 m) |
|---|---|
| Overall Width | 32 in (0.8 m) |
| Lowered Platform Height | 38 in (1.0 m) |
| Stowed Height (Rails Up) | 77.5 in (2.0 m) |
| Stowed Height (Rails Down) | 63.5 in (1.6 m) [Optional] |
| Platform Length (Inside) | 84 in (2.1 m) |
| Platform Width (Inside) | 28 in (0.7 m) |
| Extension Deck (Roll Out) | 3 ft (0.9 m) |
| Ground Clearance (Stowed) | 3.5 in (8.9 cm) |
| Ground Clearance (Raised) | 0.75 in (1.9 cm) |
| Wheelbase | 69 in (1.8 m) |
Weight 1 spec
| Operating Weight | 3,510 lb (1,592 kg) |
|---|
Power / Engine 1 spec
| System Voltage | 24 V DC |
|---|
Hydraulics / Fluids 1 spec
| Tank Capacity | 7.93 gal (30 L) |
|---|
