Aerial Lift · Snorkel
Snorkel SR1331 Specs
Quick-reference specifications for the Snorkel SR1331 aerial lift, taken from the manufacturer’s spec sheet.
- Max. lift capacity
- 6,033 kg
- Weight
- 11,090 kg
Performance 7 specs
| Max. lift capacity | 6,033 kg |
|---|---|
| Max. forward reach | 5.4 m |
| Max. drive speed | 40 km/h |
| Raise/lower time | 20/14 sec |
| Frame levelling | 10° |
| Outside turning radius | 4.5 m |
| Tires | 445/65 R22.5 in |
Dimensions 6 specs
| Max. lift height (A) | 9.5 m |
|---|---|
| Overall width (B) | 2.3 m |
| Stowed height (C) | 2.56 m |
| Length to fork face (D) | 6.15 m |
| Wheelbase | 2.9 m |
| Ground clearance | 410 mm |
Weight 1 spec
| Weight | 11,090 kg |
|---|
Power / Engine 1 spec
| Fuel capacity | 120 L |
|---|
Hydraulics / Fluids 3 specs
| Hydraulic flow (per minute) | 100 L |
|---|---|
| Hydraulic pressure | 230 bar |
| Hydraulic oil capacity | 150 L |
