Terex SS-636C (Square Shooter) Specs
Quick-reference specifications for the Terex SS-636C (Square Shooter) telehandler, compiled from published specifications.
- Maximum Lift Capacity
- 6,000 lb2,722 kg
- Maximum Lift Height
- 36 ft11.0 m
- Maximum Forward Reach
- 21 ft6.4 m
- Operating Weight with Forks
- 21,080 lb9,562 kg
Performance 6 specs
| Maximum Lift Capacity | 6,000 lb (2,722 kg) |
|---|---|
| Maximum Lift Height | 36 ft (11.0 m) |
| Maximum Forward Reach | 21 ft (6.4 m) |
| Payload at Maximum Reach | 2,000 lb (905 kg) |
| Turning Radius (outside tire) | 12 ft 11 in (3.94 m) |
| Maximum Travel Speed | 17.2 mph (27.7 km/h) |
Dimensions 7 specs
| Overall Length | 22 ft 5 in (6.83 m) |
|---|---|
| Overall Width | 8 ft 6 in (2.59 m) |
| Overall Height | 8 ft 4 in (2.54 m) |
| Ground Clearance | 1 ft 5 in (0.43 m) |
| Wheelbase | 10 ft 4 in (3.15 m) |
| Reach at Maximum Height | 30 in (0.76 m) |
| Fork Dimensions | 2 in × 4 in × 48 in (5.1 cm × 10.2 cm × 1.22 m) |
Weight 1 spec
| Operating Weight with Forks | 21,080 lb (9,562 kg) |
|---|
Power / Engine 8 specs
| Engine Make/Model | John Deere PowerTech 4045T |
|---|---|
| Net Engine Power | 99-100 hp (73.8 kW) |
| Power @ RPM | 99 hp @ 2,500 rpm |
| Number of Cylinders | 4 |
| Transmission | 3-speed Powershift |
| Drive Type | 4-wheel drive |
| Tire Size | 1300 × 24 12-ply |
| Fuel Capacity | 30 gal (113.6 L) |
Hydraulics / Fluids 2 specs
| Hydraulic Oil Capacity | 34 gal (128.7 L) |
|---|---|
| Alternator | 95 AMP |
