Yale GP60N Specs
Quick-reference specifications for the Yale GP60N forklift, taken from the manufacturer’s spec sheet.
- Rated capacity
- 6000 lb2722 kg
- Gradeability @ 1mph (1.6kph) RL/NL
- 24/24 %
Performance 7 specs
| Rated capacity | 6000 lb (2722 kg) |
|---|---|
| Outside Turning Radius (OTR) | 93.5 in (2374 mm) |
| Travel Speed RL/NL | 11.5/11.6 mph (18.5/18.7 km/h) |
| Lift Speed, Standard 2-Stage LFL RL/NL | 104/114 ft/min (.53/.58 m/s) |
| Drawbar Pull @ 1mph (1.6kph) RL/NL | 3769/2488 lb (1710/1129 kg) |
| Maximum Drawbar Pull RL/NL | 4501/2488 lb (2042/1129 kg) |
| Gradeability @ 1mph (1.6kph) RL/NL | 24/24 % |
Dimensions 24 specs
| Load Center Distance | 24.0 in (610 mm) |
|---|---|
| Length, Center of Drive Wheel to Face of Forks | 19.5 in (495 mm) |
| Wheelbase | 66.9 in (1700 mm) |
| Tire Type – Cushion, Solid, Pneumatic | Pneumatic |
| Tire Size, Front | 28×9-15 |
| Tire Size, Rear | 6.50×10 |
| Height, Mast Lowered | 86.4 in (2195 mm) |
| Lift Height, Top of Fork (TOF) | 120 in (3068 mm) |
| Free Lift Height, Limited Free Lift Mast (TOF) | 3.9 in (100 mm) |
| Height of Standard Overhead Guard | 85.9 in (2182 mm) |
| Height of Lowered Overhead Guard | 83.3 in (2115 mm) |
| Height of Cab | 88.1 in (2239 mm) |
| Step Height | 18.2 in (462 mm) |
| Tow pin height | 18.2 in (462 mm) |
| Length To Face of Forks | 108.1 in (2746 mm) |
| Rear Overhang (Steer Axle Center to Counterweight) | 21.0 in (534 mm) |
| Departure Angle | 36 % |
| Overall Width, Standard Tread | 46.7 in (1186 mm) |
| Overall Width, Wide Tread | 53.3 in (1353 mm) |
| Forks, Thickness x Width x Length | 2.0 X 4.9 X 42 in (50 X 125 X 1067 mm) |
| Maximum Fork Spread, Outside Dimensions | 39.2 in (996 mm) |
| Ground Clearance Below Mast RL | 6.0 in (152 mm) |
| Ground Clearance, Center of Wheelbase NL | 7.2 in (182 mm) |
| Breakover Angle | 53 % |
Weight 4 specs
| Weight, Standard Truck NL | 9890 lb (4490 kg) |
|---|---|
| Weight, Standard Truck RL | 15890 lb (7210 kg) |
| Axle Loading Front/Rear NL | 3929/5960 lb (1782/2703 kg) |
| Axle Loading Front/Rear RL | 13808/2082 lb (6263/944 kg) |
Power / Engine 8 specs
| Engine | Yanmar 2.2 L |
|---|---|
| Engine Manufacturer and Model | Yanmar 2.2 L |
| Power Output @ RPM | 56 hp @ 2530 (42 kW @ 2530) |
| Torque @ RPM | 128 ft-lb @ 1690 (174 N-m @ 1690) |
| Battery Type | Maintenance Free |
| Volts/Cold Cranking Amps | 12/530 V/A |
| Transmission Type, Standard | Electronic Powershift |
| Standard Speeds, Forward – Reverse | 1 – 1 |
Hydraulics / Fluids 3 specs
| Oil Flow for Attachments | 16 gal/min (60 L/min) |
|---|---|
| Hydraulic Tank Capacity (Drain and Refill) | 12.3 gal (46.4 L) |
| Fuel Tank Capacity (Gas & Diesel Powered Units Only) | 10.5 gal (39.9 L) |
