Caterpillar DP135 Specs

Quick-reference specifications for the Caterpillar DP135 forklift, taken from the manufacturer’s spec sheet.

Performance 11 specs

Load capacity	13500 kg
Load centre distance	600 mm
Mast tilt, forwards/backwards	6 / 12 °
Minimum distance between centres of rotation	1510 mm
Travel speed, with/without load	34/34 km/h
Lifting speed, with/without load	0.35 / 0.38 m/s
Lowering speed, with/without load	0.5 m/s
Maximum drawbar pull, with/without load (5 min short duty)	110000/41000 N
Gradeability, with/without load	33.3/23.8 %
Rated / nominal output to ISO 1585	114.0 kW
Rated speed to DIN 70 020	2000 rpm

Wheelbase	3100 mm
Tyre dimensions, front	11.00-20-16PR
Tyre dimensions, rear	11.00-20-16PR
Track width (centre of tyres), front	1695 mm
Track width (centre of tyres), rear	1795 mm
Height with mast lowered (see tables)	3150 mm
Lift height (see tables)	3000 mm
Overall height with mast raised	4650 mm
Height to top of overhead guard	2775 mm
Seat height	1690 mm
Tow coupling height	540 mm
Overall length	5775 mm
Length to fork face (includes fork thickness)	4555 mm
Overall width	2360 / – mm
Fork dimensions (thickness, width, length)	1220x200x85 mm
Fork carriage to DIN 15 173 A/B/no	No
Fork carriage width	2274 mm
Working aisle width with 1000 x1200 mm pallets, crosswise	6265 mm
Working aisle width with 800 x1200 mm pallets, crosswise	6465 mm
Working aisle width with 800 x1200 mm pallets, lengthwise	6065 mm
Turning circle radius	4300 mm

Max torque	537 Nm

Service brakes (mechanical/hydraulic/electric/pneumatic)	Mechanical/Hydraulic
Maximum operating pressure for attachments	206 bar
