Caterpillar GC70KSTR Specs
Quick-reference specifications for the Caterpillar GC70KSTR forklift, taken from the manufacturer’s spec sheet.
- Capacity at rated load center
- 15,500 lb7,000 kg
- Gradeability loaded at 1 mph (1.6 kph)
- 20.5 %
Performance 11 specs
| Capacity at rated load center | 15,500 lb (7,000 kg) |
|---|---|
| Tilt forward / backward | 6 / 9 degrees |
| Minimum outside turning radius | 97.2 in (2,470 mm) |
| Speeds travel speed loaded / empty | 12.7 / 14.0 mph (20.5 / 22.5 km/h) |
| Speeds lift speed loaded / empty | 71 / 77 fpm (0.36 / 0.39 m/s) |
| Lowering speed loaded / empty | 106 / 77 fpm (0.54 / 0.39 m/s) |
| Gradeability loaded at 1 mph (1.6 kph) | 20.5 % |
| Gradeability maximum loaded / empty | 26.0 / 21.0 % |
| Axle load with rated load front / rear | 32,756 / 4,420 lb (14,771 / 2,064 kg) |
| Brakes service type | foot, hydraulic |
| Brakes parking type | hand, mechanical |
Dimensions 17 specs
| Tire type | cushion |
|---|---|
| Lift w / standard maximum fork height (top of forks) | 92.9 in (2,360 mm) |
| Two-stage mast free fork height | 6.5 in (165 mm) |
| Forks thickness x length x width | 2.6 x 48.0 x 6.0 in (65 x 1,220 x 150 mm) |
| Fork spacing out-to-out minimum / maximum | 16.3 / 47.8 in (414 / 1,214 mm) |
| Length to fork face | 107.5 in (2,730 mm) |
| Width with standard tires | 56.7 in (1,440 mm) |
| Overall dimensions with lowered mast | 84.6 in (2,150 mm) |
| Height seat height | 50.6 in (1,285 mm) |
| Height top of overhead guard | 88.8 in (2,255 mm) |
| Height with extended mast | 140.9 in (3,580 mm) |
| Tire size front, standard | 28x12x22 in |
| Tire size rear | 22x8x16 in |
| Tread width front, standard tires | 44.5 in (1,130 mm) |
| Tread width rear standard tires | 45.7 in (1,160 mm) |
| Ground clearance at lowest point of mast | 3.1 in (80 mm) |
| Ground clearance at center of wheel base | 7.9 in (200 mm) |
Weight 1 spec
| Axle load without load front / rear | 7,601 / 14,076 lb (3,449 / 6,386 kg) |
|---|
Power / Engine 5 specs
| Engine manufacturer and model | GM V6 |
|---|---|
| Engine continuous output (S.A.E. gross) | 92.5 HP (69.0 kW) |
| Engine maximum torque (S.A.E. gross) | 220 lb-ft (31.0 Nm/rpm) |
| Engine cylinder / displacement | 6.0 / 262 cu in (4,300 L) |
| Transmission type | powershift |
