Doosan G40S-5 Specs

Quick-reference specifications for the Doosan G40S-5 forklift, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Max. gradeability Loaded at 1.0 mph (1.7km / h): 33.5 %

Performance 10 specs

Load Capacity at rated load center	4,000 kg
Load Center	600 mm
Tilt of Mast Forward / Backward	8 / 10 deg
Turning Radius Minimum outside	2,820 mm
Travel Speed Loaded / Unloaded	19.5 / 20.5 km/h
Lifting Speed Loaded / Unloaded	500 / 540 mm/s
Lowering Speed Loaded / Unloaded	480 / 450 mm/s
Max. drawbar pull Loaded at 1.0 mph (1.6km / h)	3,430 kg
Max. gradeability Loaded at 1.0 mph (1.7km / h)	33.5 %
Brakes Service	shoe / disc

Dimensions 16 specs

Tire type	P
Max. Fork Height with STD 2-stage mast	3,000 mm
Free Lift	160 mm
Forks Length x Width x Thickness	1,050x150x50 mm
Fork Spacing(Min x Max)	310 x 1,182 mm
Length to Fork Face	3,150 mm
Overall Width	1,451 mm
Overall Dimensions Mast Lowered Height	2,230 mm
Mast Extended Height	4,270 mm
Overhead Guard Height	2,230 mm
Seat Height	1,255 mm
Load Moment Center	561 mm
Tires Size, Front	300×15-18
Tread Width Front / Rear	1,153 / 1,115 mm
Ground Clearance Loaded at the lowest point	160 mm
Loaded at center of wheelbase	205 mm

Weight 3 specs

Total Service Weight, Unloaded	6,180 kg
Axle Load Loaded, Front / Rear	8,980 / 1,200 kg
Unloaded, Front / Rear	2,660 / 3,520 kg

Power / Engine 8 specs

Power type	LPG
Battery Voltage / Ampere	12 / 75 V/AH
Engine Model	G643 (E)
Rated Power(DIN) HP/rpm	93 / 2,450
Rated Power(DIN) kW/rpm	69 / 2,450
Maximum Torque kgm/rpm	31/ 1,400
Cylinders / Displacements CC	6 / 4,294
Transmission Type	powershift

Hydraulics / Fluids 1 spec

Hydraulic Pressure System	190 bar
