Genie GTH-4010 SX Spec Sheet
Quick-reference specifications for the Genie GTH-4010 SX. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
Forward reach maximum: 6.07 m
Overall width, stabilisers extended: 2.93 m
Lifting capacity maximum: 4,000 kg
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Lifting capacity maximum | 4,000 kg |
|---|---|
| Lift capacity at maximum height | 3,500 kg |
| Lift capacity at maximum reach | 2,500 kg |
| Forward reach maximum | 6.07 m |
| Inside/outside turning radius | 1.8 m/3.85 m |
Dimensions
| Lifting height maximum | 9.82 m |
|---|---|
| Reach at maximum height | 65 cm |
| Height | 2.41 m |
| Height at steering wheel | 1.65 m |
| Width | 2.25 m |
| Inside cab width | 78 cm |
| Wheelbase | 2.75 m |
| Length at front wheels | 4.39 m |
| Length at fork-holder plate | 6.06 m |
| Ground clearance | 40 cm |
| Overall width, stabilisers extended | 2.93 m |
Weights & Electrical
| Track | 1.85 m |
|---|---|
| Extension/retraction speed | 20 sec/24 sec |
Powertrain & Systems
| Section 5 in x 1.77 in Tyres (DIN | 70361) |
|---|---|
| POWER Engine Deutz TD2011 L04W 4-cylinder Turbo Diesel | 91 hp (68 kW), Tier 3 |
| Fuel | 90 L |
| Low emission engine conforms to UE 97/68 directives. GOST R | 50950-96 |
| Brunel Drive Newark NG24 | 2DE |
Hydraulics & Capacities
| Hydraulic output/pressure | 87 L/min-280 bars |
|---|
Lubricants & Fluids
| Engine oil | 10 L |
|---|---|
| Hydraulic oil | 80 L |
