Genie GTH-4013 EX Spec Sheet
Quick-reference specifications for the Genie GTH-4013 EX. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
Forward reach maximum: 9.08 m
Overall width, stabilisers extended: 2.89 m
Lift capacity chart (with stabilisers): 57.2900.0217
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Lift capacity chart (with stabilisers) | 57.2900.0217 |
|---|---|
| Lifting capacity maximum | 4,000 kg |
| Lift capacity at maximum height | 3,000 kg |
| Lift capacity at maximum reach | 1,250 kg |
| Forward reach maximum | 9.08 m |
| Inside/outside turning radius | 2.42 m/4.65 m |
Dimensions
| Lifting height maximum with stabilisers | 12.99 m |
|---|---|
| Lifting height maximum without stabilisers | 12.80 m |
| Reach at maximum height | 1.90 m |
| Height | 2.40 m |
| Height at steering wheel | 1.60 m |
| Width | 2.32 m |
| Inside cab width | 78 cm |
| Wheelbase | 2.95 m |
| Length at front wheels | 4.79 m |
| Length at fork-holder plate | 6.06 m |
| Ground clearance | 39 cm |
| Overall width, stabilisers extended | 2.89 m |
Weights & Electrical
| Track | 1.92 m |
|---|---|
| Standards Compliance EU Machinery Directive | 98/37/CE |
Powertrain & Systems
| Drive speed max. | 35 km/h |
|---|---|
| Chassis levelling on front axle +/- | 6° |
| Section 4.5 in x 2 in Tyres (DIN | 70361) |
| Engine Perkins 1104 D-44T 4-cylinder Turbo diesel | 74 kW (99 hp), Tier 3 |
| Low emission engine conforms to EU Directive | 97/68/EC stage III |
| Brunel Drive Newark NG24 | 2DE |
Lubricants & Fluids
| Engine oil | 7 L |
|---|---|
| Hydraulic oil | 150 L |
