Boom Lift · Genie
Genie S-40XC Specs
Quick-reference specifications for the Genie S-40XC boom lift, taken from the manufacturer’s spec sheet.
- Lift capacity max. – unrestricted
- 660 lb300 kg
- Platform height max.
- 39 ft 6 in12.04 m
- Working height max.
- 45 ft 6 in14.04 m
- Gradeability – stowed
- 45 %
Performance 15 specs
| Working height max. | 45 ft 6 in (14.04 m) |
|---|---|
| Horizontal reach max. | 31 ft 1 in (9.47 m) |
| Below ground reach | 1 ft (0.30 m) |
| Lift capacity max. – unrestricted | 660 lb (300 kg) |
| Lift capacity max. – restricted | 1,000 lb (454 kg) |
| Platform rotation | 160° |
| Turntable rotation | 360° |
| Drive speed – stowed (tires) | 4.0 mph (6.40 km/h) |
| Drive speed – stowed (TraX) | 2.5 mph (4 km/h) |
| Drive speed – raised (tires) | 0.68 mph (1.1 km/h) |
| Drive speed – raised (TraX) | 0.68 mph (1.1 km/h) |
| Gradeability – stowed | 45 % |
| Sound Pressure level (ground workstation) | 89 dBA |
| Sound Pressure level (platform workstation) | 77 dBA |
| Vibrations | < 2.5 (m/s²) |
Dimensions 12 specs
| Platform height max. | 39 ft 6 in (12.04 m) |
|---|---|
| Height – stowed (tires) | 8 ft 3 in (2.51 m) |
| Height – stowed (TraX) | 8 ft 5 in (2.56 m) |
| Length – stowed (tires) | 26 ft 4 in (8.03 m) |
| Length – stowed (TraX) | 26 ft 4 in (8.03 m) |
| Width (tires) | 8 ft 2 in (2.49 m) |
| Width (TraX) | 8 ft 1 in (2.46 m) |
| Wheelbase | 8 ft (2.44 m) |
| Ground clearance – center (tires) | 1 ft .5 in (0.32 m) |
| Ground clearance – center (TraX) | 1 ft (0.30 m) |
| Height under counterweight | 3 ft 4 in (1.02 m) |
| Turntable tailswing | 36 in (0.97 m) |
Weight 6 specs
| Weight (tires) | 14,124 lb (6,407 kg) |
|---|---|
| Weight (TraX) | 15,364 lb (6.969 kg) |
| Tire contact pressure | 92 psi (634 kPa) |
| Track contact pressure | 20 psi (138 kPa) |
| Occupied floor pressure (tires) | 162 psf (7.76 kPa) |
| Occupied floor pressure (TraX) | 164 psf (7,84 kPa) |
Hydraulics / Fluids 2 specs
| Hydraulic tank capacity | 38 gal (144 L) |
|---|---|
| Fuel tank capacity | 35 gal (132 L) |
