Genie S-65TRAX Specs
Quick-reference specifications for the Genie S-65TRAX boom lift, taken from the manufacturer’s spec sheet.
- Lift capacity
- 500 lb227 kg
- Platform height maximum (with Trax)
- 65 ft 2 in19.86 m
- Working height maximum (with Trax)
- 71 ft 2 in21.86 m
- Gradeability stowed – 2WD
- 30%
Performance 16 specs
| Working height maximum (with Trax) | 71 ft 2 in (21.86 m) |
|---|---|
| Horizontal reach maximum | 56 ft 2 in (17.10 m) |
| Below ground reach | 8 ft 11 in (2.72 m) |
| Lift capacity | 500 lb (227 kg) |
| Platform rotation | 160° |
| Vertical jib rotation | 135° (+78° /-57°) |
| Turntable rotation | 360° continuous |
| Drive speed – 4WD stowed (with Trax) | 2.3 mph (3.7 km/h) |
| Drive speed – raised or extended | 0.68 mph (1.1 km/h) |
| Gradeability stowed – 2WD | 30% |
| Gradeability stowed – 4WD | 45% |
| Turning radius – inside with Trax | 12 ft (3.66 m) |
| Turning radius – outside with Trax | 22 ft 3 in (6.80 m) |
| Sound pressure level (ground workstation) | 83 dBA |
| Sound pressure level (platform workstation) | 79 dBA |
| Vibration | <8 ft 2 in/s² (<2.5 m/s²) |
Dimensions 11 specs
| Platform height maximum (with Trax) | 65 ft 2 in (19.86 m) |
|---|---|
| Platform length – 8 ft model | 3 ft (91 cm) |
| Platform length – 6 ft model | 2 ft 6 in (76 cm) |
| Height – stowed with Trax | 9 ft 1 in (2.77 m) |
| Length – stowed | 31 ft 2 in (9.5 m) |
| Length – transport (jib tucked under) | 25 ft (7.60 m) |
| Width – with Trax | 8 ft 6 in (2.59 m) |
| Wheelbase | 8 ft 2.5 in (2.5 m) |
| Ground clearance – centre Trax | 1 ft 5 in (43 cm) |
| Turntable tailswing (with Trax) | 3 ft 9 in (1.14 m) |
| Trax – track system – 4 point | Loegering QTS-R42 |
Power / Engine 1 spec
| Auxiliary power unit | 12 V DC |
|---|
Hydraulics / Fluids 2 specs
| Hydraulic tank capacity | 45 gal (170 L) |
|---|---|
| Fuel tank capacity (Diesel) | 35 gal (132 L) |
