Haulotte SIGMA 46 PRO Specs

Quick-reference specifications for the Haulotte SIGMA 46 PRO aerial lift, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Platform height: 44 ft 11 in
Working height: 51 ft 6 in
Weight: 15,325 lb
Gradeability: 25 %

Performance 8 specs

Working height	51 ft 6 in
Horizontal outreach	26 ft 5 in
Up and over clearance	24 ft 3 in
Turntable rotation	355 °
Drive speed	3.1 mph
Maximum wind speed rating	28 mph
Gradeability	25 %
Turning radius – outside	12 ft 10 in

Dimensions 10 specs

Platform height	44 ft 11 in
Length	21 ft 10 in
Width	5 ft 9 in
Wheelbase	6 ft 7 in
Ground clearance	7 in
Platform size	3 ft 11 in x 2 ft 7 in
Height – stowed	6 ft 7 in
Length – transport	21 ft 10 in
Tailswing	0 in
Tires	27 x 10 in

Weight 1 spec

Weight	15,325 lb

Haulotte SIGMA 46 PRO spec sheet (PDF)
