Telehandler · Ingersoll Rand
Ingersoll Rand VR-1044C Specs
Quick-reference specifications for the Ingersoll Rand VR-1044C telehandler, taken from the manufacturer’s spec sheet.
- Operating Weight
- 27,265 lb12393 kg
Performance 13 specs
| Max Forward Reach | 29 ft 4 in (8941 mm) |
|---|---|
| Max Reach @ Max Lift Height | 2 ft 8 in (813 mm) |
| Max Reach @ Practical Placement Height | 6 ft 0 in (1829 mm) |
| Max Reach Below Grade w/ Standard Carriage | 2 ft 1 in (635 mm) |
| Turning Radius – To Outside of Tires | 12 ft 3 in (3683 mm) |
| Turning Radius – To Inside of Tires | 7 ft 2 in (2184 mm) |
| Frame Leveling at Boom Angle Less Than 40° – Right | 10° |
| Frame Leveling at Boom Angle Less Than 40° – Left | 10° |
| Boom Type | 3-stage |
| Telescope Extend Speed | 16.2 seconds |
| Telescope Retract Speed | 14.2 seconds |
| Boom Raised | 13.7 seconds |
| Boom Lowered | 11.7 seconds |
Dimensions 11 specs
| Overall Length (less forks) | 21 ft 2 in (6452 mm) |
|---|---|
| Overall Width | 8 ft 6 in (2591 mm) |
| Overall Height | 7 ft 1 in (2159 mm) |
| Wheelbase | 10 ft 8 in (3251 mm) |
| Drive Axle to Carriage Front | 5 ft 7 in (1702 mm) |
| Ground Clearance | 1 ft 4 in (406 mm) |
| Tread Width | 7 ft 3 in (2210 mm) |
| Boom Extension | 23 ft 7 in (7188 mm) |
| Max Lift Height | 44 ft 5 in (13538 mm) |
| Practical Placement Height | 42 ft 6 in (12955 mm) |
| Max Boom Angle | 70° |
Weight 1 spec
| Operating Weight | 27,265 lb (12393 kg) |
|---|
Power / Engine 4 specs
| Make / Model | Cummins QSB4.5-30-T |
|---|---|
| Fuel / Cooling | Diesel / liquid |
| SAE net hp | 110 hp (82.1 kW) |
| Transmission | 3-speed powershift with soft shift |
Hydraulics / Fluids 2 specs
| Carriage Rotation | 113° |
|---|---|
| Fuel Tank Capacity | 35 gal (132.65 L) |
