JLG 150HAX Specs
Quick-reference specifications for the JLG 150HAX boom lift, taken from the manufacturer’s spec sheet.
- Platform Capacity—Restricted
- 1,000 lb454 kg
- Platform Height
- 150 ft45.72 m
- Weight
- 58,100 lb26,354 kg
- Gradeability
- 31%
Performance 11 specs
| Horizontal Outreach | 79 ft 3 in (24.16 m) |
|---|---|
| Below Ground Reach | 30 ft 4 in (9.25 m) |
| Swing | 360° Continuous |
| Platform Capacity—Restricted | 1,000 lb (454 kg) |
| Platform Capacity—Unrestricted | 500 lb (227 kg) |
| Drive Speed | 3 mph (4.8 kmph) |
| Gradeability | 31% |
| Turning Radius (Inside) – Axles Retracted | 14 ft 10 in (4.52 m) |
| Turning Radius (Inside) – Axles Extended | 14 ft 7 in (4.45 m) |
| Turning Radius (Outside) – Axles Retracted | 27 ft (8.23 m) |
| Turning Radius (Outside) – Axles Extended | 30 ft 1 in (9.17 m) |
Dimensions 12 specs
| Platform Height | 150 ft (45.72 m) |
|---|---|
| Up and Over Height | 79 ft 11 in (24.36 m) |
| Platform Size | 36 x 96 in (0.91 x 2.44 m) |
| Overall Width—Axles Retracted | 11 ft 6 in (3.51 m) |
| Overall Width—Axles Extended | 18 ft (5.49 m) |
| Tailswing (Stowed) | 17 ft 7 in (5.36 m) |
| Stowed Height | 14 ft (4.27 m) |
| Stowed Height (Platform Tilted) | 10 ft 6 in (3.2 m) |
| Stowed Length | 39 ft 5 in (12.01 m) |
| Stowed Length (Platform Tilted) | 41 ft 7 in (12.67 m) |
| Wheelbase | 18 ft (5.49 m) |
| Ground Clearance | 11 in. (28 cm) |
Weight 2 specs
| Weight | 58,100 lb (26,354 kg) |
|---|---|
| Max. Ground Bearing Pressure | 120 psi (8.4 kg/cm2) |
Power / Engine 1 spec
| Diesel Engine | Cummins 4B3.9C 76 hp (57 kW) |
|---|
Hydraulics / Fluids 1 spec
| Fuel Tank Capacity | 68 gal (257.41 L) |
|---|
