Rough Terrain Scissor Lift · JLG

JLG 2632R Specs

Quick-reference specifications for the JLG 2632R scissor lift, taken from the manufacturer’s spec sheet.

Download Spec Sheet (PDF)View PDF

Platform Capacity (Indoor Only): 230 kg
Capacity on Platform Extension: 120 kg
Platform Height (Indoor Only): 7.80 m
Gradeability: 25%

Performance 6 specs

Platform Capacity (Indoor Only)	230 kg
Capacity on Platform Extension	120 kg
Lift/Lower Time	56/42 Seconds
Drive Speed–Elevated	0.8 km/h
Drive Speed–Lowered	3.2 km/h
Gradeability	25%

Dimensions 9 specs

Platform Height (Indoor Only)	7.80 m
Platform Height–Lowered	1.10 m
Platform Railing Height	1.13 m
Platform Size	0.70 m x 2.10 m
Platform Extension	0.86 m
Overall Width	0.81 m
Overall Length	2.40 m
Wheelbase	1.90 m
Ground Clearance	0.10 m

Power / Engine 2 specs

Batteries	4 x 6 V 220 amp-hr
Charger	27 amp
