JLG E300AJP Specs
Quick-reference specifications for the JLG E300AJP boom lift, taken from the manufacturer’s spec sheet.
- Platform Capacity
- 500 lb227 kg
- Platform Height
- 29 ft 5 in8.96 m
- Weight
- 15,400 lb6,985 kg
- Gradeability
- 25%
Performance 9 specs
| Horizontal Outreach | 20 ft 1 in (6.12 m) |
|---|---|
| Up and Over Reach | 13 ft 2 in (4.01 m) |
| Platform Capacity | 500 lb (227 kg) |
| Up and Over Clearance | 13 ft 2 in (4.01 m) |
| Swing | 350 Degrees Non-Continuous |
| Max Drive Speed | 4.5 mph (7.2 km/h) |
| Gradeability | 25% |
| Turning Radius Inside (2WS/4WS) | 5 ft (1.52 m) |
| Turning Radius Outside (2WS/4WS) | 10 ft 2 in (3.1 m) |
Dimensions 9 specs
| Platform Height | 29 ft 5 in (8.96 m) |
|---|---|
| Platform Width | 30 in (76 cm) |
| Platform Length | 48 in (1.22 m) |
| Machine Width | 4 ft (1.22 m) |
| Tailswing | 0 in (0 cm) |
| Machine Height | 6 ft 7 in (2.01 m) |
| Machine Length | 18 ft 10 in (5.74 m) |
| Wheelbase | 5 ft 5 in (1.65 m) |
| Ground Clearance | 4 in (10 cm) |
Weight 2 specs
| Weight | 15,400 lb (6,985 kg) |
|---|---|
| Ground Bearing Pressure | 170 psi (11.95 kg/cm²) |
Power / Engine 2 specs
| Batteries | 8 x 6 V, 305 amp-hr |
|---|---|
| Batteries, 375 ah | 375 ah, 305 ah AGM |
Hydraulics / Fluids 1 spec
| Hydraulic System – Capacity | 2.1 gal (7.95 L) |
|---|
