JLG X700AJ Specs
Quick-reference specifications for the JLG X700AJ boom lift, compiled from published specifications.
- Platform Capacity
- 440 lb200 kg
- Platform Height
- 69 ft 7 in21.20 m
- Working Height
- 76 ft23.16 m
- Gradeability
- 40%
Performance 10 specs
| Platform Height | 69 ft 7 in (21.20 m) |
|---|---|
| Working Height | 76 ft (23.16 m) |
| Horizontal Outreach | 36 ft 6 in (11.13 m) |
| Swing | 360° Non-continuous |
| Platform Capacity | 440 lb (200 kg) |
| Jib Rotation Range | 85° (-1° to -86°) |
| Gradeability | 40% |
| Slope Tolerance | 14° |
| Drive Speed | 0.8 mph (1.3 km/h) |
| Ground Bearing Pressure (Outriggers) | 43 psi (3.0 kg/cm²) |
Dimensions 8 specs
| Machine Length | 19 ft 8 in (5.99 m) |
|---|---|
| Machine Width | 3 ft 3 in (0.99 m) |
| Machine Height | 6 ft 7 in (1.99 m) |
| Platform Length | 58 in (1.47 m) |
| Platform Width | 31 in (0.79 m) |
| Track Length | 5 ft 9 in (1.75 m) |
| Outrigger Footprint Length | 13 ft 1 in (3.99 m) |
| Outrigger Footprint Width | 13 ft 1 in (3.99 m) |
Weight 1 spec
| Machine Weight | 7050 lb (3197.83 kg) |
|---|
Power / Engine 3 specs
| Engine Type (Electric) | 100 Ah 72 V Lithium-Ion |
|---|---|
| Engine Type (Gasoline) | Honda GX440 15 hp |
| Fuel Tank Capacity (Gasoline) | 2 gal (5.68 L) |
