Linde D12SF Specs
Quick-reference specifications for the Linde D12SF forklift, taken from the manufacturer’s spec sheet.
Performance 6 specs
| Load capacity/Load Q | 1.2 / 1.8 t |
|---|---|
| Tyres | rubber, SE, pneumatic, polyurethane V+P/P |
| Turning radius Wa | 1950 mm |
| Travel speed, with/without load | 10 / 10 km/h |
| Service brake | Electro-magnetic |
| Sound pressure level LpAZ (at the driver’s seat) | 67 dB (A) |
Dimensions 19 specs
| Load centre distance c | 600 mm |
|---|---|
| Tyre size, front | Ø 254 x 102 |
| Auxiliary wheels (dimensions) | 2x Ø 140 x 50 |
| Track width, front b | 484 mm |
| Track width, rear b | 380 mm |
| Height of mast, lowered h | 1315 mm |
| Free lift h | 795 mm |
| Lift h | 1724 mm |
| Height of mast, extended h | 2244 mm |
| Initial lift h | 125 mm |
| Height, lowered h | 86 mm |
| Overall length l | 2170 mm |
| Length to fork face l | 1020 mm |
| Overall width b1/b | 770 mm |
| Fork dimensions DIN ISO 2331 s/e/l | 55 x 180 x 1150 mm |
| Width of fork carriage b | 710 mm |
| Fork spread b | 560 mm |
| Distance between wheel arms/loading surfaces b | 196 mm |
| Ground clearance, centre of wheelbase m | 20 mm |
Weight 2 specs
| Service weight | 1348 kg |
|---|---|
| Axle load without load, front/rear | 943 / 405 kg |
Power / Engine 6 specs
| Drive motor rating S2 60 min | 3 kW |
|---|---|
| Lift motor rating at S3 15% | 2.2 kW |
| Battery according to DIN 43531/35/36 A,B,C,no | 43 535 / B |
| Battery weight (± 5%) | 287 kg |
| Power consumption according to VDI cycle | 1.01 kWh/h |
| Type of drive unit | LAC |
