Forklift · Linde
Linde HT25T Specs
Quick-reference specifications for the Linde HT25T forklift, from the manufacturer’s spec sheet and published specifications.
- Operating Weight
- 11,200 lb
- Max Gradeability
- 30%
Performance 5 specs
| Round Steering Wheel | 4-Function Hydraulic Valve |
|---|---|
| Load Capacity | 5,000 lb (2,268 kg) |
| Max Travel Speed | 18.6 mph |
| Max Gradeability | 30% |
| Turning Radius | 95.3 in (2,420 mm) |
Dimensions 9 specs
| Ground Clearance Mast | m1 |
|---|---|
| Ground Clearance Chassis | m2 |
| Wheelbase | 66.4 in (1,687 mm) |
| Overall Width | 74.8 in |
| Overall Height | 97.3 in |
| Mast Height Lowered | 86.8 in |
| Mast Height Raised | 185.8 in |
| Ground Clearance | 6.7 in |
| Load Center | 24 in (600 mm) |
Weight 1 spec
| Operating Weight | 11,200 lb |
|---|
Power / Engine 2 specs
| Engine Type | 4-cylinder, liquid-cooled |
|---|---|
| Engine Displacement | 2.5 liters |
Hydraulics / Fluids 3 specs
| Individual Hydraulic Control Levers | 3-Function Hydraulic Valve |
|---|---|
| Hydraulic Pump Flow | 19.8 gpm |
| Operating Pressure | 2,900 psi |
