Linde MV05 Specs
Quick-reference specifications for the Linde MV05 forklift, taken from the manufacturer’s spec sheet.
- Capacity – Total vehicle capacity up to 126″ elevation
- 1,000 lb
Performance 8 specs
| Capacity – Total vehicle capacity up to 126″ elevation | 1,000 lb |
|---|---|
| Capacity – Operators compartment | 300 lb |
| Capacity – Front work platform | 500 lb |
| Capacity – Rear hideaway tray | 200 lb |
| Standard travel speeds | 0 to 3.4 mph |
| Ground level travel (high speed option) | up to 5 mph |
| Lift speed | up to 42 fpm |
| Turning radius – MV05-126 & 162 | 52.5 in |
Dimensions 2 specs
| Minimum Turn Aisle | 72 in |
|---|---|
| W dimension – MV05-126 & MV05-162 | 31.5 in |
Power / Engine 3 specs
| Battery Compartments – MV05-126 & J1-162 | 29.1 in x 7.9 in x open |
|---|---|
| Battery Compartments – MV05-192 | 29.1 in x 11 in x open |
| System voltage | 24 V |
