Telehandler · Manitou
Manitou MT625H EASY Specs
Quick-reference specifications for the Manitou MT625H EASY telehandler, taken from the manufacturer’s spec sheet.
Performance 10 specs
| Max. capacity | 2500 kg |
|---|---|
| Lifting | 8.9 secs |
| Lowering | 6.0 secs |
| Tyres | 12-16.5 12PR SKS CL TUBELESS |
| Automatic Negative Handbrake – KUBOTA STAGE III A | V2607-DI-T-E3B |
| Laden drawbar pull | 3550 daN |
| Turning radius (over tyres) | 3.31 m |
| Noise at driving position (LpA) | 76 dB |
| Environmental noise (LwA) | 104 dB |
| Vibration to whole hand/arm | <2.50 m/s² |
Dimensions 9 specs
| Maximum lifting height | 5.85 m |
|---|---|
| Max. lifting height | 5.85 m |
| Front wheel centre to carriage | 0.99 m |
| Wheelbase | 2.30 m |
| Overall length to carriage | 3.90 m |
| Overall width of cab | 0.79 m |
| Inside tyre width | 1.49 m |
| Overall width | 1.81 m |
| Standard forks (length x width x thickness) | 1200 x 125 x 45 mm |
Power / Engine 4 specs
| Power | 49 HP (36 kW) |
|---|---|
| Max. torque | 180 Nm |
| Oil engine | 11.2 l |
| Fuel | 63 l |
Hydraulics / Fluids 2 specs
| Hydraulic oil | 115 l |
|---|---|
| Unladen weight (with forks) | 4710 kg |
