Equipment Spec Sheet
Skyjack SJ82T Spec Sheet
Quick-reference specifications for the Skyjack SJ82T. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
Platform Height: 82’ (24.99 m)
D Stowed Height: 9′ 10” (3.00 m)
Capacity 500 / 750 lbs (227 /: 340 kg)
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Platform Height | 82’ (24.99 m) |
|---|---|
| C Tailswing | 4′ 8” (1.42 m) |
| Gradeability | 45% |
| Turning Radius (Inside) | 11′ 6” (3.51 m) |
| Turning Radius (Outside) | 21′ (6.40 m) |
| Capacity 500 / 750 lbs (227 / | 340 kg) |
Dimensions
| Work Height | 88’ (26.82 m) |
|---|---|
| A Platform Size | 36” x 96” (0.91 x 2.44 m) |
| B Stowed Width | 8′ 2″ (2.49 m) |
| D Stowed Height | 9′ 10” (3.00 m) |
| F Stowed Length | 37’ 10” (11.53 m) |
| H Wheelbase | 11′ (3.35 m) |
| I Ground Clearance | 16” (0.41 m) |
Weights & Electrical
| temperatures can reach | 14°F / -10°C (Includes cold start engine oil, battery blanket, |
|---|---|
| Skyjack Asia Room 608 Building | 46, No.555 Guiping Road |
| asia.sales@skyjack.com | |
| Skyjack Head Office 55 Campbell Road, Guelph, ON Canada N1H | 1B9 |
| Horizontal Reach | 72’ 6” (22.10 m) |
| Weight | 37,600 lbs (17,055 kg) |
Powertrain & Systems
| Axle Oscillation | 4” (10.16 cm) |
|---|---|
| Drive Speed (High speed) | 3 mph (4.8 km/h) |
| Tire Size | 18-625 |
| Diesel Engine Deutz TD2.9L – | 74 HP (55 KW) |
Hydraulics & Capacities
| Fuel Tank Capacity | 45 gal. (170 L) |
|---|---|
| Hydraulic Reservoir | 60 gal. (227 L) |
