Equipment Spec Sheet
Skyjack SJ8831RT Spec Sheet
Quick-reference specifications for the Skyjack SJ8831RT. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
B Raised Platform Height: 9.45 m
D Overall Width: 2.21 m
F Stowed Height (Rails Up): 2.67 m
Capacity (Overall): 908 kg
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Colour coded and numbered wiring system | 30% Gradeability |
|---|---|
| B Raised Platform Height | 9.45 m |
| C Lowered Platform Height | 1.50 m |
| Gradeability | 30% |
| Turning Radius (Inside) | 4.01 m |
| Turning Radius (Outside) | 6.30 m |
| Capacity (Overall) | 908 kg |
Dimensions
| Drivable at full height with roll out decks fully extended Axle based | 4WD |
|---|---|
| A Work Height | 11.45 m |
| D Overall Width | 2.21 m |
| E Overall Length | 3.71 m |
| F Stowed Height (Rails Up) | 2.67 m |
| G Stowed Height (Rails Down) | 1.99 m |
| H Platform Width (Inside Dimension) | 1.70 m |
| Platform Length (Inside Dimension) | 5.7 m |
| Ground Clearance | 0.20 m |
| Wheelbase | 2.27 m |
Weights & Electrical
| ACCESSORIES AND OPTIONS Dual | 1.22 m powered extension decks |
|---|---|
| Weight | 5,684 kg |
Powertrain & Systems
| Disc brake system on rear axle | 29hp Kubota Diesel engine on roll out tray |
|---|---|
| Drive Speed (Stowed) | 4.5 km/h |
| Drive Speed (Raised) | 0.4 km/h |
| Tyre Size 10 x | 16.5 |
Hydraulics & Capacities
| Airline to platform | 3.5kW hydraulic generator |
|---|
