Scissor Lift · Skyjack
Skyjack SJ8841RTE Specs
Quick-reference specifications for the Skyjack SJ8841RTE scissor lift, taken from the manufacturer’s spec sheet.
- Capacity (Overall)
- 1,500 lb680 kg
- Work Height
- 47 ft14.32 m
- Gradeability
- 30%
Performance 13 specs
| Work Height | 47 ft (14.32 m) |
|---|---|
| Extension Deck | 4 ft (1.22 m) |
| Gradeability | 30% |
| Turning Radius (Inside) | 158 in (4.01 m) |
| Turning Radius (Outside) | 248 in (6.30 m) |
| Lift Time (With Rated Load) | 56 sec |
| Lower time (With Rated Load) | 53 sec |
| Drive Speed (Stowed) | 3.5 mph (5.6 km/h) |
| Drive Speed (Raised) | 0.6 mph (1 km/h) |
| Capacity (Overall) | 1,500 lb (680 kg) |
| Local Floor Load (With Rated Load) | 136 psi (938 kPa) |
| Overall Floor Load (With Rated Load) | 163 psf (8 kPa) |
| Maximum # of Persons | 5 |
Dimensions 10 specs
| Raised Platform Height | 41 ft (12.50 m) |
|---|---|
| Lowered Platform Height | 69 in (1.75 m) |
| Overall Width | 87 in (2.21 m) |
| Overall Length | 139 in (3.53 m) |
| Stowed Height (Rails Up) | 114 in (2.90 m) |
| Stowed Height (Rails Down) | 87.5 in (2.22 m) |
| Platform Width (Inside Dimension) | 67 in (1.70 m) |
| Platform Length (Inside Dimension) | 134 in (3.40 m) |
| Ground Clearance | 8 in (0.20 m) |
| Wheelbase | 89.3 in (2.27 m) |
