Skyjack SJIII 4626 Specs
Quick-reference specifications for the Skyjack SJIII 4626 scissor lift, taken from the manufacturer’s spec sheet.
- Capacity (Overall)
- 1,000 lb454 kg
- Work Height
- 32 ft9.75 m
- Weight
- 4,700 lb2,132 kg
- Gradeability
- 30%
Performance 17 specs
| Solid rubber, non-marking tires | 800W AC inverter |
|---|---|
| Work Height | 32 ft (9.75 m) |
| Extension Deck (Roll Out) | 4 ft (1.22 m) |
| Gradeability | 30% |
| Turning Radius (Inside) | 47.5 in (1.21 m) |
| Turning Radius (Outside) | 93.5 in (2.37 m) |
| Lift Time (With Rated Load) | 54 sec |
| Lower time (With Rated Load) | 32 sec |
| Drive Speed (Stowed) | 2 mph (3.2 km/h) |
| Drive Speed (Raised) | 0.6 mph (1 km/h) |
| Capacity (Overall) | 1,000 lb (454 kg) |
| Distributed Capacity (Main Platform) | 700 lb (318 kg) |
| Distributed Capacity (Extension Deck) | 300 lb (136 kg) |
| Local Floor Load (With Rated Load) | 235 psi (1620 kPa) |
| Overall Floor Load (With Rated Load) | 191 psf (9 kPa) |
| Maximum # of Persons | 3 |
| Wind Rating | 28 mph (12.5 m/s) |
Dimensions 11 specs
| Raised Platform Height | 26 ft (7.92 m) |
|---|---|
| Overall Width | 46 in (1.17 m) |
| Overall Length | 91 in (2.31 m) |
| Stowed Height (Rails Up) | 84.5 in (2.15 m) |
| Stowed Height (Rails Down) | 70.5 in (1.79 m) |
| Platform Width (Inside Dimension) | 42 in (1.07 m) |
| Platform Length (Inside Dimension) | 84 in (2.13 m) |
| Ground Clearance (Stowed) | 3.5 in (8.89 cm) |
| Ground Clearance (Raised) | 0.75 in (1.91 cm) |
| Wheelbase | 69 in (1.75 m) |
| Tire Size | 16 x 5 x 12 |
Weight 1 spec
| Weight | 4,700 lb (2,132 kg) |
|---|
