Snorkel S3215E Specs
Quick-reference specifications for the Snorkel S3215E aerial lift, taken from the manufacturer’s spec sheet.
- Platform capacity (SWL)
- 600 lb
- Max. working height
- 21 ft
- Weight
- 2,700 lb
- Gradeability
- 25%
Performance 9 specs
| Max. working height | 21 ft |
|---|---|
| Platform capacity (SWL) | 600 lb |
| Max. wind speed | 28 mph |
| Max. drive speed (stowed) | 2.0 mph |
| Max. drive speed (elevated) | 0.4 mph |
| Raise/lower time | 20/36 sec |
| Gradeability | 25% |
| Inside turning radius | 4 in |
| Outside turning radius | 64.25 in |
Dimensions 12 specs
| Max. platform height (A) | 15 ft |
|---|---|
| Platform size (stowed) | 28.25 in x 63.75 in |
| Platform size (extended) | 28.25 in x 99.75 in |
| Deck extension length | 36 in |
| Overall length (C) (with step) | 70.4 in |
| Overall length (C) (with step removed) | 68.3 in |
| Overall width (D) | 32 in |
| Stowed height (B) | 79 in |
| Min. height (guardrails folded) | 62.6 in |
| Ground clearance (stowed) | 2.63 in |
| Ground clearance (elevated) | 0.75 in |
| Max. drive height | 15 ft |
Weight 1 spec
| Weight | 2,700 lb |
|---|
