Boom Lift · Terex
Terex TA40 Specs
Quick-reference specifications for the Terex TA40 boom lift, compiled from published specifications.
- Maximum Working Height
- 46.6 ft14.2 m
Performance 4 specs
| Maximum Cage Floor Height | 40.0 ft (12.2 m) |
|---|---|
| Maximum Working Height | 46.6 ft (14.2 m) |
| Maximum Working Outreach | 27.2 ft (8.3 m) |
| Maximum Speed (Booms Stowed) | 5 km/hr (3 mph) |
Dimensions 5 specs
| Length (Closed) | 17.1 ft (5.2 m) |
|---|---|
| Width (Closed) | 4.9 ft (1.50 m) |
| Height (Closed) | 6.5 ft (1.985 m) |
| Standard Platform Dimensions | 4.4 ft × 2.3 ft (1.35 m × 0.7 m) |
| Outside Turning Circle | 12.8 ft (3.9 m) |
Weight 1 spec
| Unladen Weight | 14,330 lb (6500 kg) |
|---|
