Boom Lift · Terex
Terex TA80RT Specs
Quick-reference specifications for the Terex TA80RT boom lift, taken from the manufacturer’s spec sheet.
- Gradeability
- 25%15°
Performance 12 specs
| Platform (maximum) | 80 ft (24.4 m) |
|---|---|
| Horizontal Reach | 45 ft 7 in (13.86 m) |
| Load Capacity (maximum) | 500 lb (227 kg) |
| Platform Rotation | 180° |
| Turret Rotation | 360° Continuous |
| Turning radius – Inside | 13 ft 6 in (4.11 m) |
| Turning radius – Outside | 22 ft 5 in (6.81 m) |
| Travel Speed – Stowed | 0-3.0 mph (0-5.0 km/h) |
| Travel Speed – Elevated | 0-0.5 mph (0-0.75 km/h) |
| Gradeability | 25% (15°) |
| Controls – Boom Functions | Proportional |
| Controls – Drive | Proportional |
Dimensions 10 specs
| Height-Working (maximum) | 86 ft (26.2 m) |
|---|---|
| Length (overall) | 26 ft 4 in (8 m) |
| Width (maximum) | 7 ft 6 in (2.3 m) |
| Boom Angle – Above Horizontal | 72° |
| Boom Angle – Below Horizontal | 0° |
| Platform Dimensions | 36 in x 72 (0.9 x 1.8 m) |
| Wheelbase | 9 ft 2 in (2.8 m) |
| Wheel Track | 7 ft 6 in (2.3 m) |
| Tires | 15 x 19. Monofilled |
| Ground Clearance | 20 in (5.2 m) |
Weight 1 spec
| Approx. Shipping Weight | 33,400 lb (15,200 kg) |
|---|
Hydraulics / Fluids 2 specs
| Fuel Tank Capacity | 32 gal (120 L) |
|---|---|
| Reservoir Capacity | 43 gal (160 L) |
