Genie GTH-4017 AU Spec Sheet
Quick-reference specifications for the Genie GTH-4017 AU. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
Forward reach maximum: 12.55 m
Overall width, outriggers extended: 2.95 m
Lifting capacity maximum: 4,000 kg
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Lifting capacity maximum | 4,000 kg |
|---|---|
| Lift capacity at maximum height | 2,500 kg |
| Lift capacity at maximum reach | 600 kg |
| Forward reach maximum | 12.55 m |
| Inside/outside turning radius 2.15 m / | 4.50 m |
| Drawbar pull 8,200 kg / | 7,250 kg |
Dimensions
| Lifting height maximum with outriggers | 16.72 m |
|---|---|
| Lifting height maximum without outriggers | 16.59 m |
| Reach at maximum height | 0.59 m |
| Height | 2.61 m |
| Height at steering wheel | 1.65 m |
| Width | 2.45 m |
| Inside cab width | 0.78 m |
| Wheelbase | 2.85 m |
| Length at front wheels | 4.70 m |
| Length at fork-holder plate | 6.49 m |
| Ground clearance | 0.42 m |
| Overall width, outriggers extended | 2.95 m |
Weights & Electrical
| Track | 1.98 m |
|---|---|
| EU Machinery Directive | 98/37/CE Operating cab conforms to ISO3471 (ROPS) and ISO3449 (FOPS) |
Powertrain & Systems
| Drive speed | 35 km/h |
|---|---|
| Chassis levelling on the front axle +/- | 8° |
| Section 4.7 in x 2 in Tyres (DIN | 70361) |
| Engine Perkins 1104 D-44T turbo diesel | 74.5 kW (100 hp), Tier 3 |
| Fuel | 135 L |
| Low emission engine conforms to EU Directive | 97/68/EC stage III |
Lubricants & Fluids
| Engine oil | 7 L |
|---|---|
| Hydraulic oil | 150 L |
