JLG 12010 Spec Sheet
Quick-reference specifications for the JLG 12010. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
Platform capacity: 200 kg 1
Working height: 12.00 m
Platform height: 10.00 m
Horizontal outreach: 5.00 m
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Working height | 12.00 m |
|---|---|
| Platform height | 10.00 m |
| Horizontal outreach | 5.00 m |
| Horizontal outreach with platform rotation | 5.22 m |
| Up and over height | 7.00 m |
| Swing (not continous) | 343° |
| Platform capacity | 200 kg 1 |
| C. Tailswing | 15 cm |
| Turning radius (outside) | 3.20 m |
| Turning radius (inside) | 1.53 m |
| Gradeability | 12% |
Dimensions
| specified | 3 Not available in all platform sizes |
|---|---|
| the work at height specialists details contact | Tel: 0844 35.7 7750 |
| A. Platform size (W x L) 1.10 m x | 0.70 m |
| B. Overall width | 1.20 m |
| D. Stowed height | 1.99 m |
| E. Overall length | 3.85 m |
| Overall length with platform rotation | 4.07 m |
| F. Wheelbase | 1.60 m |
| G. Ground clearance | 8 cm |
Weights & Electrical
| Two Wheel Hydraulic Drive 24V | 620 A/hr full traction batteries |
|---|---|
| On-board | 110V/230V battery charger |
| Sculptured polyester hoods | 1 Only available on machines equipped with |
| Accessories Heavy duty steel roller mast with | 343º |
| Chain slack detection system | 2 degree tilt alarm and indicator light |
| battery charger 24V | 840 A/hr Gel batteries & on-board |
| On-board | 110V/230V HF battery |
| charger 18 x 7 x | 12.5 solid non marking tyres |
| info@skyreachaccess.com | |
| www.skyreachaccess.com Toucan | 1210 |
| Machine weight | 5,200 kg |
| Machine weight with platform rotation | 5,300 kg |
| Electrical system | 24V DC |
| Batteries 24V – | 620 A/hr |
| Charger | 24V – 70A |
| Electrical motor 4.8 kW | 24V DC |
Powertrain & Systems
| platform option. NB 110V or | 230V power must be |
|---|---|
| Available Options | 120 degree powered platform rotator 1 |
| AC power cable to platform | 8 mm air line to platform |
| Drive speed – lowered | 3.50 km/h |
| Drive speed – elevated | 0.65 km/h |
| Tyres (solid) 21 x 8 x | 15 |
| Drive motors | 2 Hydraulic motors |
Hydraulics & Capacities
| Maximum ground bearing pressure | 17.7 kg/cm2 |
|---|---|
| Hydraulic system | 55 L |
