JLG 670SJ Specs
Quick-reference specifications for the JLG 670SJ boom lift, taken from the manufacturer’s spec sheet.
- Platform Capacity (Restricted)
- 750 lb340 kg
- Platform Height
- 66 ft 10 in20.36 m
- Weight
- 25,341 lb11,494 kg
- Gradeability 4WD
- 45%
Performance 10 specs
| Drive Speed | 3.8 mph (6.1 km/h) |
|---|---|
| Horizontal Outreach | 57 ft 1 in (17.40 m) |
| Swing | 360 Degrees Continuous |
| Platform Capacity (Restricted) | 750 lb (340 kg) |
| Platform Capacity (Unrestricted) | 550 lb (250 kg) |
| Jib Range of Articulation | 132 Degrees (+71, -61) |
| Drive Speed 4WD | 3.8 mph (6.1 km/h) |
| Gradeability 4WD | 45% |
| Leveling Capacity (Fore/Aft) | 10 Degrees |
| Leveling Capacity (Side to side) | 10 Degrees |
Dimensions 10 specs
| Platform Height | 66 ft 10 in (20.36 m) |
|---|---|
| Tailswing | 4 ft (1.22 m) |
| Jib Length | 6 ft (1.83 m) |
| Platform Width | 36 in (0.91 m) |
| Platform Length | 96 in (2.44 m) |
| Machine Width | 8 ft 2.4 in (2.50 m) |
| Machine Height | 9 ft 1.2 in (2.74 m) |
| Machine Length | 35 ft 5 in (10.68 m) |
| Wheelbase | 8 ft 9.9 in (2.69 m) |
| Ground Clearance | 13 in (33 cm) |
Weight 2 specs
| Weight | 25,341 lb (11,494 kg) |
|---|---|
| Max. Ground Bearing Pressure | 85 psi (5.87 kg/cm²) |
Power / Engine 2 specs
| Diesel Engine – Deutz T4F | 67 hp (50 kW) |
|---|---|
| Auxiliary Power | 12 V DC |
Hydraulics / Fluids 2 specs
| Fuel Tank Capacity | 31 gal (117 L) |
|---|---|
| Hydraulic System – Capacity | 34 gal (129 L) |
