JLG 740AJ Spec Sheet
Quick-reference specifications for the JLG 740AJ. Includes extracted performance, dimensions, capacities, and other details found in the source PDF.
Platform Capacity-Unrestricted: 500 lb
Platform Height: 74 ft
Horizontal Outreach 51 ft: 10 in.
Fuel Tank Capacity: 40 gal
BHESPECS note: Specs can vary by configuration, serial range, and market. Always confirm against the machine data plate and the source PDF.
Performance
| Platform Height | 74 ft |
|---|---|
| Horizontal Outreach 51 ft | 10 in. |
| Up and Over Height 25 ft | 1 in. |
| Swing | 360° Continuous |
| Platform Capacity-Unrestricted | 500 lb |
| Jib Length | 6 ft |
| Jib Range of Articulation | 130° (+70, -60) |
Weights & Electrical
| This machine meets or exceeds applicable OSHA Regulations in 29 CFR 1910.67, | 29 CFR |
|---|
Powertrain & Systems
| Drive Speed 4WD | 3.0 mph |
|---|---|
| Dual Fuel Engine GM Vortec | 3000 MPFI |
| JLG Industries, Inc. | 1 JLG Drive |
Hydraulics & Capacities
| Platform Rotator | 180° Hydraulic |
|---|---|
| Max. Ground Bearing Pressure | 84 psi |
| Fuel Tank Capacity | 40 gal |
