JLG P25 Spec Sheet
Quick-reference specifications for the JLG P25. Includes key performance, dimensions, weights, and lubricants/fluids (when listed in the source spec material).
Max Working Height: 9.50 m
Max Platform Height (approx.): 7.70 m
Rated Capacity: 160 kg (DC) / 120 kg (AC)
Stowed Height: 1.99 m
BHESPECS note: Specs can vary by configuration/market. Always confirm with the machine data plate and the exact PDF you’re referencing.
Performance
| Max Working Height | 9.50 m |
|---|---|
| Max Platform Height (approx.) | 7.70 m |
| Rated Load | 160 kg (DC models) / 120 kg (AC models) |
| Hydraulic System Pressure | 13.5 MPa |
Dimensions
| Overall Width | 0.75 m |
|---|---|
| Overall Length | 1.31 m |
| Width w/ Outriggers | 1.44 m |
| Length w/ Outriggers | 1.69 m |
| Stowed Height | 1.99 m |
| Ground Clearance | 0.05 m |
| Platform Dimensions | 0.66 × 0.66 × 1.10 m |
Weights & Electrical
| Machine Weight (AC) | 365 kg |
|---|---|
| Machine Weight (DC) | 380 kg |
| Battery Charger (AC Input) | AC 90–240V / 50–60 Hz |
| Battery Charger (DC Output) | DC 24V / 30A |
Lubricants & Fluids
Mast Grease: EP-MPG
Mast Chains Oil: HYDO-68
Hydraulic Oil: HYDO-32
Mast Chains Oil: HYDO-68
Hydraulic Oil: HYDO-32
Important: Do not use ATF (Dexron type) in the hydraulic reservoir.
| Hydraulic Circuit Amount (P25) | 5.5 L |
|---|---|
| Hydraulic Reservoir Capacity (P25) | 5.3 L |
Hydraulic oil service: Check daily (oil should reach the “MAX” gauge mark). First oil change at ~6 months, then interval ~2 years.
