JLG Toucan 32E Specs
Quick-reference specifications for the JLG Toucan 32E scissor lift, compiled from published specifications.
- Platform Capacity
- 500 lb226.8 kg
- Platform Height
- 32 ft 3 in9.83 m
Performance 10 specs
| Platform Height | 32 ft 3 in (9.83 m) |
|---|---|
| Up and Over Height | 22 ft 9 in (6.95 m) |
| Horizontal Outreach | 15 ft 1 in (4.6 m) |
| Platform Capacity | 500 lb (226.8 kg) |
| Max Travel Speed (Platform Lowered) | 3.4 mph (5.47 km/h) |
| Travel Speed (Elevated) | 0.43 mph (0.7 km/h) |
| Jib Range of Articulation | 120 Degrees |
| Swing | 345 Degrees Non-continuous |
| Turning Radius (Inside) | 2 ft 5 in |
| Turning Radius (Outside) | 8 ft 6 in |
Dimensions 8 specs
| Machine Length | 11 ft 10 in (3.61 m) |
|---|---|
| Machine Width | 3 ft 9 in (1.19 m) |
| Machine Height (Stowed) | 6 ft 7 in (1.99 m) |
| Ground Clearance | 4 in (0.1 m) |
| Wheelbase | 5 ft 3 in |
| Platform Length | 2 ft 4 in (0.7 m) |
| Platform Width | 3 ft 5 in (1.05 m) |
| Ground Bearing Pressure | 185 psi (13 kg/cm²) |
Weight 1 spec
| Machine Weight | 10,140 lb (4,600 kg) |
|---|
Power / Engine 1 spec
| Batteries | 48 V – 260 A/hr (8x6V) |
|---|
Hydraulics / Fluids 1 spec
| Hydraulic Reservoir Capacity | 4 gal (14.99 L) |
|---|
