Aerial Lift · Niftylift
Niftylift HR17N Specs
Quick-reference specifications for the Niftylift HR17N aerial lift, taken from the manufacturer’s spec sheet.
- Platform capacity
- 500 lb225 kg
- Platform height
- 49 ft 6 in15 m
- Working height
- 56 ft17 m
- Weight
- 17155 lb/16870 lb7780 kg/7650 kg
Performance 7 specs
| Working height | 56 ft (17 m) |
|---|---|
| Outreach | 32 ft (9.7 m) |
| Up and over clearance | 11 ft 6 in (3.5 m) |
| Platform capacity | 500 lb (225 kg) |
| Platform rotation | 150° |
| Drive speed | 2.2 mph (3.5 km/h) |
| Gradeability | 25% / 14º |
Dimensions 6 specs
| Platform height | 49 ft 6 in (15 m) |
|---|---|
| Platform size | 4 ft 11 in x 2 ft 8 in (1.5 m x 0.8 m) |
| Stowed height | 6 ft 6 in (1.99 m) |
| Width | 4 ft 11 in (1.5 m) |
| Length | 16 ft 2 in (4.93 m) |
| Wheelbase | 21 ft (6.4 m) |
Weight 1 spec
| Weight | 17155 lb/16870 lb (7780 kg/7650 kg) |
|---|
