JLG 1230ES Specs
Quick-reference specifications for the JLG 1230ES scissor lift, compiled from published specifications.
- Platform Capacity
- 500 lb227 kg
- Working Height
- 18 ft5.49 m
- Operating Weight
- 1,740 lb790 kg
- Gradeability
- 25%
Performance 8 specs
| Maximum Platform Height | 12 ft (3.66 m) |
|---|---|
| Working Height | 18 ft (5.49 m) |
| Lift/Lower Time | 12 / 12 sec |
| Drive Speed – Platform Lowered | 3 mph (4.83 km/h) |
| Drive Speed – Platform Elevated | 0.5 mph (0.80 km/h) |
| Gradeability | 25% |
| Platform Capacity | 500 lb (227 kg) |
| Maximum Persons | 2 |
Dimensions 9 specs
| Overall Length | 4 ft 6 in (1.36 m) |
|---|---|
| Overall Width | 2 ft 6 in (0.76 m) |
| Overall Height Stowed | 5 ft 5 in (1.66 m) |
| Ground Clearance | 2.6 in (6.6 cm) |
| Platform Size | 27 x 49.5 in (0.68 x 1.25 m) |
| Wheelbase | 3 ft 5 in (1.04 m) |
| Ground Entry Height | 1 ft 10 in (0.56 m) |
| Platform Dimension A | 4 ft 2 in (1.26 m) |
| Platform Dimension B | 2 ft 3 in (0.69 m) |
Weight 1 spec
| Operating Weight | 1,740 lb (790 kg) |
|---|
Power / Engine 4 specs
| Drive System | 24 V Electric, 8 hp (6 kW) |
|---|---|
| Electrical System Voltage | 24 V DC |
| Batteries | 4 x 6 V, 220 amp-hr |
| Power | 120 V/240 V – 50/60 Hz |
Hydraulics / Fluids 3 specs
| Hydraulic Reservoir Capacity | 1.88 gal (7.1 L) |
|---|---|
| Maximum Lift Pressure | 1600 psi (110 bar) |
| Maximum Steer Pressure | 1250 psi (86 bar) |
